 VALVE SPECIFICATIONS
MAX. OPER. PRESS. DIFF.
AC DC
200 200 200 200 200 200 200 200 200 200 200 200 200 200
MIN. OPER. PRESS. DIFF.
3 3 3 3 3 3 3
ORIFICE SIZE N.C
1/2 3/4 1
1 1/2 2
3
3
CV FACTOR N.C.
4.0
5.8 13.0 29.0 46.0 76.0 98.0
PIPE SIZE
1/2 NPT 3/4 NPT 1 NPT
1 1/2 NPT 2 NPT
2 1/2 NPT 3 NPT
VALVE NUMBER
E828B12DCCM E828Y19DCCM E828D13DCCM E828E14DCCM E828F16DCCM E828W17DCCM E828W18DCCM
ORDERING INFORMATION:
1/2-14 NPT CONDUIT
1.87 47.6
4.46 113.2
2X 1/2-14 NPT
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (E828B12DCCM 120/60) REPAIR PACK (2KE828B12DD AC)
NO OPERATOR AVAILABLE
2.86 72.7
2.56 .67
65
17
SERIES 80 MODEL E828
SERIES 80
1/2" NPT PORTS
MODEL E827
2WNC INTERNAL PILOT
1/2 NPT PORTS
EXPLOSION PROOF
2WNC INTERNAL PILOT EXPLOSION PROOF
