Body Options
For Most Port Connectors
Constructed of stainless steel, brass, anodized aluminum, nylon, and other plastics. Manual override, metering, metered bypass, manifold mount, flange mount, 90° port left and right, orifice metering, and some other special options.
FLOW ADJUSTING OPTIONS
