Page 35 - Peter Paul 2019 Catalog

AC
500 250 (500) 200 (400) 125 (300) 100 (200)
DC
500 250 (500) 200 (400) 125 (250) 100 (200)
N.C.
1/32 3/64 1/16 3/32 1/8
N.C.
.024 .052 .095 .156 .284 .404 .500 .700 1.000
1/8 NPT PORTS
22G7DGM 22H7DGM 22J7DGM 22K7DGM 22N7DGM
22O7DGM 22P7DGM 22R7DGM —
1/4 NPT PORTS
22G9DGM 22H9DGM 22J9DGM 22K9DGM 22N9DGM 22O9DGM 22P9DGM 22R9DGM 22S9DGM
1/8 NPT PORTS
22G7DCM 22H7DCM 22J7DCM 22K7DCM 22N7DCM 22O7DCM 22P7DCM 22R7DCM —
1/4 NPT PORTS
22G9DCM 22H9DCM 22J9DCM 22K9DCM 22N9DCM 22O9DCM 22P9DCM 22R9DCM 22S9DCM
2.90 73.8
1/4 OR 1/8 NPT OUTLET
.88 22.3
.44 11.1
1.55 39.4
2X 10-32 UNF-2B
.88 22.3
1/2-14 NPT CONDUIT
1/4 OR 1/8 NPT INLET
.31 MFT
1.63 41.4
1.61 41
1.75 44.4
2X .34 8.8
SERIES 20 MODEL 22
SERIES 20 MODEL 22
SERIES 20
SERIES 20
2WNC
2WNC
MODEL 22
MODEL 22
CONDUIT COIL CONNECTION
GROMMET HOUSING WITH LEADS
2WNC CONDUIT CONNECTION
VALVE SPECIFICATIONS
2WNC
GROMMET HOUSING WITH LEADS
MAX. OPER. PRESS. DIFF.+
ORIFICE SIZE CV FACTOR
VALVE NUMBER GROMMET HOUSING
CONDUIT HOUSING
75 50 5/32 50 25 3/16 20 5 1/4 15 — 5/16
* FKM seals not recommended for + Ratings in brackets are optional
ORDERING INFORMATION:
pressure ratings above 500 PSI. extended ratings; consult factory.
.44 11.1
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (22N9DCM 120/60) REPAIR PACK (K22NDD AC)
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (O22N9DCM 120/60)
