Page 37 - Peter Paul 2019 Catalog

1/4 OR 1/8 NPT INLET
.88 22.3
.44 11.1
2X 10-32 UNF-2B
.88 22.3
1/2-14 NPT CONDUIT
1/4 OR 1/8 NPT CYL
.31 MFT
.44 11.1
EXHAUST
2.75 70
1.56 39.7
1.63 .86 41.4 21.8
1.75 44.4
1.61 2X .34 41 8.8
SERIES 20 MODEL 23
SERIES 20 MODEL 23
SERIES 20
SERIES 20
3WNC EXHAUST TO ATMOSPHERE
3WNC EXHAUST TO ATMOSPHERE
MODEL 23
MODEL 23
CONDUIT COIL CONNECTION
GROMMET HOUSING WITH LEADS
3WNC EXHAUST TO ATMOSPHERE CONDUIT CONNECTION
VALVE SPECIFICATIONS
3WNC EXHAUST TO ATMOSPHERE GROMMET HOUSING WITH LEADS
MAX. OPER. PRESS. DIFF.+
ORIFICE SIZE N.C. N.O.
1/32 1/32 3/64 1/16 1/16 1/16 1/16 3/32 3/32 3/32
1/8 3/32
1/8 1/8 3/16 3/32 3/16 1/8
CV FACTOR N.C. N.O.
.024 .024 .052 .095 .095 .095 .095 .156 .156 .156 .284 .156 .284 .201 .500 .156 .500 .201 .700 .156 .700 .201
GROMMET HOUSING
VALVE NUMBER
CONDUIT HOUSING
AC
400 150 (200) 100 (135) 100 (135) 75 (100) 50 (70) 35 (40) 20
20
DC
400 150 (200) 100 (135) 100 (135) 75 (100) 50 (70) 35 (40) 20
20
1/8 NPT PORTS
23GG7DGM 23HJ7DGM 23JJ7DGM 23JK7DGM 23KK7DGM 23NK7DGM 23NN7DGM^ 23PK7DGM 23PN7DGM^ 23RK7DGM 23RN7DGM^
1/4 NPT PORTS
23GG9DGM 23HJ9DGM 23JJ9DGM 23JK9DGM 23KK9DGM 23NK9DGM 23NN9DGM^ 23PK9DGM 23PN9DGM^ 23RK9DGM 23RN9DGM^
1/8 NPT PORTS
23GG7DCM 23HJ7DCM 23JJ7DCM 23JK7DCM 23KK7DCM 23NK7DCM 23NN7DCM^ 23PK7DCM 23PN7DCM^ 23RK7DCM 23RN7DCM^
1/4 NPT PORTS
23GG9DCM 23HJ9DCM 23JJ9DCM 23JK9DCM 23KK9DCM 23NK9DCM 23NN9DCM^ 23PK9DCM 23PN9DCM^ 23RK9DCM 23RN9DCM^
15 —
15 — 1/4 1/8
1/4 3/32
^ VALVES WITH 1/8 N.O. ORIFICE ARE UL LISTED ONLY
+ Ratings in brackets are optional extended ratings; consult factory.
ORDERING INFORMATION:
WHEN ORDERING VALVES OR REPAIR PACKS ADD VOLTAGE AND FREQUENCY TO COMPLETE VALVE NUMBER. EXAMPLES: VALVE (23JK9DGV 120/60) REPAIR PACK (K23JKD AC)
WHEN ORDERING OPERATORS ADD THE LETTER “O” TO THE FRONT OF THE VALVE NUMBER, REPLACE BODY PORT NUMBER WITH THE LETTER “D”: EXAMPLE: OPERATOR (O23JK9DGV 120/60)
