20系列 >> 型号21

二位二通常开型
二位二通常开型

一系列具有选项和卓越成熟性能的阀门。应用中的标杆。介质为空气，水或其他与标配的丁腈橡胶相兼容的流体。热水，蒸汽，汽油和其他油需要特殊密封材料。
• 旗舰阀最初用于流体动力行业。
• 重型机械且由不锈钢制成。
• 真正的主力，具有成熟的性能。
• 它具有所有阀门可用的最多选项。
• 节流孔径范围从1/32"到1/8"。

PDF icon Model-21.pdf

Tabs

Operator Drawings
Operator Drawings:

Series 20 OPERATORS CONDUIT


MODEL 21 1/8-27 NPT
2WNO CONDUIT CONNECTION

MODEL 21 1/4-18 NPT
2WNO CONDUIT CONNECTION


Series 20 OPERATORS DIN


MODEL 21 1/8-27 NPT
2WNO DIN STYLE COIL

MODEL 21 1/4-18 NPT
2WNO DIN STYLE COIL


Series 20 OPERATORS EXPLOSION PROOF


MODEL 21 1/8-27 NPT
2WNO EXPLOSION PROOF

MODEL 21 1/4-18 NPT
2WNO EXPLOSION PROOF


Series 20 OPERATORS GROMMET


MODEL 21 1/8-27 NPT
2WNO GROMMET WITH LEADS

MODEL 21 1/4-18 NPT
2WNO GROMMET WITH LEADS


Series 20 OPERATORS YOKE LEADS


MODEL 21 1/8-27 NPT
2WNO MOLDED COIL WITH YOKE

MODEL 21 1/4-18 NPT
2WNO MOLDED COIL WITH YOKE


Series 20 OPERATORS YOKE SPADE


MODEL 21 1/8-27 NPT
2WNO SPADE COIL WITH YOKE

MODEL 21 1/4-18 NPT
2WNO SPADE COIL WITH YOKE



* Consult representative or factory for options and specifications
